AFS Fiberglass Pipe

Advanced Fiberglass Services is proud to introduce our own product line of fiberglass pipe to our product and services line-up.  Using our proprietary state-of-the-art advancements in fiberglass pipe fabrication, we are able to produce our pipe of the same high quality with less lead-time and at a lower cost than the competitor.  If you are interested, schedule a Lunch & Learn or Give us a Call and request a sample. Please don’t hesitate to Request a Quote!

• Primary Advantages

  • High-quality resin throughout (notice the AFS difference)
    • AFS uses a high quality resin throughout the pipe, from corrosion barrier through structural laminate.  This is what separates AFS pipe from other fiberglass pipe manufacturers.
  • Excellent for highly-corrosive applications
  • Able to withstand high operating temperatures
  • Thermal insulator
  • Electrical insulator
  • Lighter than steel alternatives
  • Stronger than plastic alternatives
  • Abrasion Resistant (upon request)

• Pressure Pipe

  • Up to 12″ diameter
  • Will withstand pressures of up to 150 PSI
  • Will withstand temperatures of up to 250° F
  • Little maintenance required

• Header Pipe

  • Fabricated custom to order
  • All fittings and flanges included
  • Low or High pressure pipe available

---

Standard & Custom Sizes

Currently In Stock

AFS is currently carrying stock of our general purpose single wall pipe.  Our general purpose single wall pipe is manufactured per industry standard PS 15-69 minimums.  The laminate consists of one resin throughout the entire structure.  From corrosion barrier through structural laminate, the same quality resin is used.

• Standard Resin (Derakane 411-350 Momentum)
• Standard Corrosion barrier (C-veil)
• Standard Laminate Structure (1 1/2 oz. chopped strand mat)
• Standard Gel Coat (Gray gel coat with UV inhibitor)
• Standard Wall Thickness (1/4″ thickness)
  • Complies with industry standard PS 15-69 minimums.  See chart below.
• Standard Sizes (2″ – 12″ diameter)
  • Currently stocking 100′ each of our general purpose pipe in sizes 4″, 6″ and 8″ diameter (10″ coming).

If our standard piping specifications do not meet your application requirements, we offer a variety of special resins, corrosion barriers, gel coats and wall thicknesses.  From Class I fire retardant pipe to abrasion-resistant liners, we have a system to meet your needs.  Our team of experienced fiberglass technicians would be happy to discuss your requirements.

Standard Size Chart

Pipe Size	Minimum Pipe Wall Thickness At Pressure Rating						Minimum Flange Thickness At Design Rating						Minimum Pipe Support Span
	25 psi inches	50 psi inches	75 psi inches	100 psi inches	125 psi inches	150 psi inches	25 psi inches	50 psi inches	75 psi inches	100 psi inches	125 psi inches	150 psi inches	25 psi feet	50 psi feet	75 psi feet	100 psi feet	125 psi feet	150 psi feet
2	3/16	3/16	3/16	3/16	3/16	3/16	1/2	1/2	1/2	9/16	5/8	11/16	6.0	6.0	6.0	6.0	6.0	6.0
3	3/16	3/16	3/16	3/16	1/4	1/4	1/2	1/2	5/8	11/16	3/4	13/16	6.5	6.5	6.5	6.5	8.0	8.0
4	3/16	3/16	3/16	1/4	1/4	1/4	1/2	9/16	11/16	13/16	7/8	15/16	7.0	7.0	7.0	8.5	8.5	8.5
6	3/16	3/16	1/4	1/4	5/16	3/8	1/2	5/8	3/4	7/8	1	1-1/16	8.0	8.0	9.0	9.0	10.0	10.5
8	3/16	1/4	1/4	5/16	3/8	7/16	9/16	3/4	7/8	1	1-1/8	1-1/4	8.5	10.0	10.0	10.5	11.0	11.5
10	3/16	1/4	5/16	3/8	7/16	1/2	11/16	7/8	1-1/16	1-3/16	1-5/16	1-7/16	9.5	10.5	11.5	12.0	12.5	13.0
12	3/16	1/4	3/8	7/16	1/2	5/8	3/4	1	1-1/4	1-7/16	1-5/8	1-3/4	10.0	11.5	12.5	13.0	13.5	14.0
14	1/4	5/16	3/8	1/2	5/8	3/4	13/16	1-1/16	1-5/16	1-1/2	1-3/4	1-7/8	11.5	12.5	13.0	14.0	15.0	15.5
16	1/4	5/16	7/16	9/16	11/16		7/8	1-3/16	1-7/16	1-5/8	1-7/8		12.0	13.0	14.0	15.5	16.5	17
18	1/4	3/8	1/2	5/8	3/4		1	1-1/4	1-1/2	1-3/4	2		12.5	14.5	15.0	16.0	15.5	17.5
20	1/4	3/8	1/2	11/16			1-1/8	1-5/16	1-5/8	1-7/8			12.5	15.0	15.5	17.0	18.0	18.5
24	1/4	7/16	5/8	13/16			1-3/8	1-1/2	1-7/8				8.5	15.0	17.0	18.5	19.0
30	5/16	1/2	3/4				1-3/4	1-7/8					9.5	17.5	19.5	21.0
36	3/8	5/8					2						10.5	19.5	21.0
42	3/8	3/4											8.0	21.0	22.5
